SilverMax® Integrated Motors
Fully Integrated Hybrid Servo Motor + Controller + Indexer + Analog and Digital I/O

SilverMax™ 23 Frame X-Series Integrated Servo

SilverMax™ 34 Frame X-Series Integrated Servo
POWER

  • Input Voltage: +12.5VDC to +48VDC, regulated
  • Input Current: 5.5A Max
 POWER

  • Driver Input Voltage: +12VDC to +72VDC, regulated
  • Driver Input Current: 20A Max
  • Processor Input Voltage: +12VDC to +48DC, regulated
COMMUNICATIONS

  • RS-485 multi-drop
  • 8-Bit ASCII
  • 9-Bit Binary
  • Modbus® RTU
  • DMX-512®
  • CANopen®
  • Baud Rates: 2400, 4800, 9600, 19.2k, 28.8k, 57.6k, 115.2k or 230.4k (250k only for DMX512)
 COMMUNICATIONS

  • RS-485 multi-drop
  • 8-Bit ASCII
  • 9-Bit Binary
  • Modbus® RTU
  • DMX-512®
  • CANopen®
  • Baud Rates: 2400, 4800, 9600, 19.2k, 28.8k, 57.6k, 115.2k or 230.4k (250k only for DMX512)
INPUTS/OUTPUTS

  • 7 Digital LVTTL Inputs or Outputs (0 to 3.3v)
  • All inputs have a light pull-up (~100k ohm to 3.3v)
  • All 7 I/O have an optional programmable pull-up/pull-down of 2.2 k ohm
  • All 7 I/O may be used as Analog Inputs: 0 to +3.3 VDC input signal range
  • IO7 has a secondary circuit to handle 0 to +10v input signal range
  • Hardware Drive Enable
  • Processor Power Backup
  • Single Cable: M16-19 connector
 INPUTS/OUTPUTS

  • 7 Digital LVTTL Inputs or Outputs (0 to 3.3v)
  • All inputs have a light pull-up (~100k ohm to 3.3v)
  • All 7 I/O have an optional programmable pull-up/pull-down of 2.2 k ohm
  • All 7 I/O may be used as Analog Inputs: 0 to +3.3 VDC input signal range
  • IO7 has a secondary circuit to handle 0 to +10v input signal range
  • Hardware Drive Enable
  • Processor Power Backup
Hybrid Servo Motors
Motors with Feedback – Many Available either IP 50 and IP65
NEMA 17 I-Grade Servo Motor
with Encoder		 NEMA 23 I-Grade Servo Motor
with Encoder		 NEMA 34 I-Grade Servo Motor
with Encoder		 NEMA 17 and 23 Mosolver™
with built-in feedback sensor

Controllers

SilverNugget™ X-Series – Supports Hybrid Servos, DC, Voice Coils



SilverSterling™ – Support Hybrid, Mosolver, 3 Phase, DC motors, Voice Coils



SilverDust™ Open Frame – Supports Hybrid Servos, DC motor, Voice



SilverDust™ Closed Frame – Supports Hybrid Servo, Stepper, DC motor


Accessories
                 Break-Out Boards                                                                                       Cables                                                                                    Regenerative Clamps



                   Power Supplies                                                QuickControl® Integrated Development Environment                                               RS-485 Adapter
